STRUCTURE
EZ MOUNTING SERVICES
Meet your business needs
International standards by a team of specialized engineers and staff. Experience of installing more than 2000 MW throughout Thailand
OUR SERVICES
Quick installation, quick connection
Control the installation on time
Accurate with KEMREX's unique technology Machine Drive Head Installation Vehicle Ready to connect the structure immediately
Durable materials
Strong from the foundation
Reach the top structure
With standard technology and materials
Managed and designed by experts
Engineered design Calculated by professional engineers With a design suitable for the area
EZ MOUNTING
PRODUCT ADVANTAGES
ENERGY ZOLUTION BY KEMREX
Solar Panel Direction : Horizontal and Vertical
Wind Speed : 30 m/s
Tilt angle : 5 - 15 Degree
Material : Bluzinc/Hot Dip Galvanized
Foundation : KEMREX Piles
Standard : ISO 9001/ASTM A123
PRODUCT DETAILS
Supported by KEMREX foundation, stable, strong and durable.
KEMREX piles are the most suitable choice for the foundation of solar installation structures.
With special features that go through the Hot-Dip Galvanized rust-proof coating process.
According to ASTM A123 standards, the piles are highly resistant to corrosion and can be used for more than 20 years.
High quality structural connectors
EZ uses high quality connection equipment such as Fitting, Hardware Bolt&Nut.
Made from SS400 steel with Hot Dip Galvanized process.
Standard lightweight solar panel mounting kit
Bluzinc combines aluminum and zinc.
Increased corrosion resistance, strength, and tensile strength higher than general materials on the market. It can also be disassembled into small parts.
And it is easy and quick to assemble.
Product information
Average weight bearing: 770 kgs / 1 tree
The weight shown is the safe weight.
At safety ratio = 2.5 times
(The load bearing capacity depends on the soil conditions in each area.)
Item No : N68 x 1200
Material : SS400
Surface : Hot Dip Galvanized
Length : 1200 mm
Diameter : 68 mm
Steel is strong and
More flexible than concrete poles
Not easily broken
Installation time is 5 times faster than before.
1 tree not more than 60 minutes
Ready to use
Can be made in various forms such as knock-down houses, building structures not exceeding 2 floors, fast work, work connected to concrete.
SPECIFICATION
01
Foundations are easy to install, fast, and require little labor for ease of area maintence. There 36 turns of thread. Has a diameter of 76 millimeters.
02
The durability of the material is ted with a salt spray test of not less than 2,000 hours, or equivalent to 40 years, along with the attached results of the durability test of the material with a salt spray test of not
less than 2,000 hours.
03
Able to support an average pressure load of 1,590 kilograms per tree. (varies according to area conditions) with list of pile calculations and engineers support.
04
Able to support the weight of an average withdrawal force of 795 kilograms per tree. (varies according to area conditions) with list of pile calculations and engineers support.
05
Able to support an average shear weight of 400 kilograms per tree. (varies according to area conditions) with list of pile calculations and engineers support.
06
Receive wind force at 30 m/sec with pile calculation list and engineers support.
